Description
Performance |
|
|---|---|
| Standby power (LTP) | 44 kVA |
| Prime power (PRP) | 40 kVA |
| Continuous power (COP) | 30 kVA |
| Power factor | 0.8 φ |
| Frequency | 50 Hz |
| Voltage | 230/400 V |
Engine Data |
|
|---|---|
| Engine Brand | Baudouin |
| Engine model | 4M06G44/5 |
| Engine Type | Four-cylinder |
| Standby Power | 35 kW |
| Prime Power | 32 kW |
| Continuous Power | 24 kW |
| Air intake type | Turbo Charged |
| Cooling mode | Water Cooling |
| Governor mode | Electronic |
| Bore x Stroke | 89mm x 92mm |
| Compression ratio | 17.5:01 |
| Rated Speed | 1500 RPM |
| Displacement | 2.3l |
| Starter Motor | 12V DC |
| Description | Diesel Generator |
Alternator Data |
|
|---|---|
| Alternator Brand | StromerPower |
| Alternator Model | Brushless, Three Phase, Four Wire |
| Standby Current | 63 Amps Per Phase |
| Prime Current | 57 Amps Per Phase |
| Continuous Current | 43 Amps Per Phase |
| Pole Number | 4 |
| Phase Number | Three Phase |
| AVR Type | SX460 |
| Excitation Mode | Self Excitation |
Canopy Data |
|
|---|---|
| Canopy Type | Silent |
| Canopy Material | Mild Steel |
| Canopy Colour | White |
| Base Material | Mild Steel |
| Base Colour | Black |
| Other Canopy Options | N/A |
Controller Data |
|
|---|---|
| Controller Brand | Smartgen |
| Controller Model | HGM420N |
| Controller Display | LCD |
| Auto Changeover Scheduling | N/A |
| Auto Shutdown Protection | Yes |
| Remote Monitoring | On Request (Optional Extra) |
| Remote Control | On Request (Optional Extra) |
Other Data |
|
|---|---|
| Changeover Switch | Manual or Automatic |
| Noise Level (dBA @ 7m) | Not Measured (Est. 72db) |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 180l |
| Fuel Consumption @ 50% load | 4.7l/h |
| Fuel Consumption @ 75% load | 7l/h |
| Fuel Consumption @ 100% load | 9.5l/h |
| Oil Type | 15W40 |
| Oil Capacity | 9.5l |
| Limited Warranty | 12 Months or 1,000 Hours. Whichever comes first. |
Dimensions & Weight (Dry) |
|
|---|---|
| Length | 2250 mm |
| Width | 950 mm |
| Height | 1150 mm |
| Weight | 1078 kgs |
Standard Features |
|
|---|---|
| Pre-Delivery Testing Filled with oil and coolant, tested under full load. |
YES |
| Pre-Delivery Inspection (PDI) Full inspection of the generator |
YES |
| User Manuals | Digital (Online) |
Optional Extras |
|
|---|---|
| Remote Monitoring (Wifi, Ethernet & GSM modules Available) | |
| Remote Control (Wifi, Ethernet & GSM modules Available) | |
| Double Axle Trailer |
Global Recognized brands:
Baudouin:
Established in 1918, Baudouin has been a key player in marine and power sectors. With a rich history, they’ve become a symbol of trust and innovation. Their engines, known for adaptability and strength, have been chosen for numerous global projects. Focused on sustainable growth, Baudouin remains a top choice.
StormerPower:
Established in 1955, StromerPower is a leader in alternator production. Their dedication to precision and performance is evident in their products. Their unwavering quality standards have positioned StromerPower as an industry favorite.
Smartgen:
Established in 1998, Smartgen leads in control system creation. They offer controllers that are user-friendly and high-performing. Committed to continuous growth, Smartgen is recognized for its reliable and modern solutions.
