Features
- Available for 48 (VDC) systems
- Output power of 5kW & 8kW
- LCD display and low idle current
- High surge capacity for motor start
- Timed overload capacity with auto shutdown
- 3-Attempt auto restart with short circuit protection
- Built in, high rate, two-stage battery charger
- Minimum local service turnaround time
- 5 YEAR WARRANTY
- Li-Ion Compatible
- Fan cooling for optimum performance and component longevity
- Audible buzzer indicating faults, overload and status
Specifications – 8000W. DC Input
- Nominal Voltage (VDC): 48.
- Max Input Amps: 200.
- Standby Power: 90W.
AC Output
- Voltage (VAC): 230V.
- Amps (A): 35A.
- Voltage Regulation: <3% RMS for entire battery voltage range.
- Frequency: 50Hz.
- Frequency Regulation: ±0.1Hz.
- Power factor: 1.
- Wave form: Pure Sine Wave.
- Peak Efficiency: <94%.
- Hardware Protection: Circuit Breaker.
- Overload Protection: Programmable Overload, Levels and Auto Retry.
Charger
- Float Voltage (VDC): 55.2.
- Maximum Current (A): 80.
- Boost Time: 1 – 3 hrs (Selectable).
- Dimensions (L x W x D): 64 x 42 x 24cm.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards.
